 Product Description


Enbon FS-Plus series is a LED display screen uses for indoor staging, exhibitions, shopping malls and other social events. The weight of the box is 40% lighter than the traditional iron box, which saves a lot of costs. Anti-knock design to avoid damage to the module, reducing maintenance and improve work efficiency. High brightness and high contrast maintain the suction cup tool before use. The iron plate is installed on the back of the module and is easy to disassemble and assemble. Current sharing gives consistent power to panel, in case of any panel power supply failure. With bringhtness control that you could adjust brightness degree to the resultt you want.


 Product Parameters


Pixel Pitch

1.25, 1.53, 1.86, 2.5, 3

LED lamp

SMD1010(P1.25) SMD1515(P1.53, P1.86) SMD2020(P2.5, P3)

Brightness

500nits(P1.25) 600nits(P1.53) 800nits(P1.86) 900nits(P2.5, P3)

Module pixel

256*128dots(P1.25) 208*104dots(P1.53) 172*86dots(P1.86) 128*64dots(P2.5) 104*52dots(P3)

Cabinet pixel

534*400dots(P1.25) 405*304dots(P1.53) 341*256dots(P1.86) 256*192dots(P2.5) 213*160dots(P3)

Module size

320*160mm (P1.25, P1.53, P1.86, P2.5, P3)

Cabinet size

640*480*85mm(P1.25, P1.53, P1.86, P2.5, P3)

Module weight

0.5kg(P1.25, P1.53, P1.86, P2.5, P3)

Cabinet Weight

5.5kg(P1.25, P1.53, P1.86, P2.5, P3)

Work humidity

10% ~ 90%

Work temperature

﹣20 ~﹢65℃

Operating system

AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI

Brightness control

256 level

Max Power

500 w/sqm(P1.25, P1.53, P1.86, P2.5, P3)
Average Power160 w/sqm(P1.25, P1.53, P1.86) 200 w/sqm(P2.5, P3)
IP ratingIP40
Control waySynchronous/Asynchronous

Viewing Angle

≥160° (horizontal), ≥160° (vertical)
Density695556dots/m2(P1.25) 401111dots/m2(P1.53) 284444dots/m2(P1.86) 160000dots/m2(P2.5) 111111dots/m2(P3)

Cabinet Materiel

Die-casting Aluminum



 Product Display





┃ Our service


CUSTOMER SERVICE

1. We can provide customers with professional product advice and purchase options.

2. All emails will be responded within 24 hours during working days.

3.We have online customer service in English, French, Korean and Japanese. You can communicate with ease, or contact us through email anytime.

4.All customers will get one-on-one service.


CUSTOMIZED SERVICE

1.We provide flexible customized services with our abundant experiences in Led screen display D&R

2.Includes product appearance design, product size, new product development, etc.

3.MOQ is depend on different customized requests.


THE AGENCY POLICY

  1. Please contact our sales department for more details.


AFTER SALE SERVICE

1.The warranty of all our products is one year. The specific after-sale plan will be free for replacement or charging a certain maintenance cost according to the specific situations.

2.According to the feedback from markets, we seldom have after-sale problems because strict product inspections are carried out before leaving the factory. And all of our products are certificated by top testing institutions such as TST certification and ATC certification Providing safe and guaranteed products is always one of our greatest strengths.
