┃ Product Description
Enbon FC-A series is a LED display screen with soft connection, a led display screen for outdoor fixed rental, commercial events and billboards, it's more lighter than normal products, making it more convenient to operate and saving more transportation cost. different kinds of pixel pitch 3.7, 5.2, 6.5, 7.8, 9.5, it makes you have different module choice of our product. Safety lock of our display enables one man to install it, by this way, clients can save a lot of time and labor costs. High brightness of our produces, but less energy consumption. clients don't have to worried about bad weather, which is a good choice for outdoor fixed rental and stage events.
┃ Product Parameters
| Pixel Pitch | Outdoor: 3.7, 5.2, 6.5, 7.8, 9.5 |
| LED lamp | Outdoor: P3.7=SMD1921 P5.2=SMD1921 P6.5=SMD2727 P7.8=SMD2727 P9.5=SMD2727 |
| Brightness | Outdoor: P3.7=5000-5500nits P5.2=5500-6000nits P6.5=5000-5500nits P7.8=5500-6000nits P9.5=6000-6500nits |
| Module pixel | Outdoor:P3.7=86*86dots P5.2=61*61dots P6.5=49*49dots P7.8=40*40dots P9.5=32*32dots |
| Cabinet pixel | Outdoor: P3.7=259*259dots P5.2=184*184dots P6.5=147*147dots P7.8=120*120dots P9.5=96*96dots |
| Module size | Outdoor:P3.7=320*320*14mm P5.2=320*320*14mm P6.5=320*320*14mm P7.8=320*320*14mm P9.5=320*320*14mm |
| Cabinet size | Outdoor:P3.7=960*960*100mm P5.2=960*960*100mm P6.5=960*960*100mm P7.8=960*960*100mm P9.5=960*960*100mm |
| Module weight | Outdoor: P3.7=1.65kg P5.2=1.65kg P6.5=1.65kg P7.8=1.65kg P9.5=1.65kg |
| Cabinet Weight | Outdoor: P3.7=28.5kg P5.2=28.5kg P6.5=28.5kg P7.8=28.5kg P9.5=28.5kg |
| Work humidity | 10％ ～ 90％ |
| Work temperature | ﹣20 ～﹢65℃ |
| Operating system | AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI |
| Gray scale | 16bits |
| Max Power | Outdoor: P3.7=600w/sqm P5.2=750w/sqm P6.5=850w/sqm P7.8=750w/sqm P9.5=900w/sqm |
| Average Power | Outdoor: P3.7=200w/sqm P5.2=250w/sqm P6.5=285w/sqm P7.8=250w/sqm P9.5=300w/sqm |
| IP rating | Outdoor: IP65 |
| Control way | Synchronous/Asynchronous |
| Viewing Angle | H140(+70/-70) deg V140(+70/-70)deg |
| Scan | Outdoor: P3.7=14scan P5.2=6scan P6.5=6scan P7.8=5scan P9.5=2scan |
| Density | Outdoor: P3.7=72972dots/m2 P5.2=36980dots/m2 P6.5=23661dots/m2 P7.8=15625dots/m2 P9.5=10000dots/m2 |
| Cabinet Materiel | Die-casting Aluminum |
