Enbon R3 series.The unique large screen of R3 series makes it easy to realize long-distance viewing.It has 500 * 500mm and 500 * 1000mm cabinets and can work at the same time.Enbon R3 rental product is the perfect choice for high-end users,Both indoor and outdoor.
┃ Product Description
Enbon R3 series.The unique large screen of R3 series makes it easy to realize long-distance viewing.It has 500 * 500mm and 500 * 1000mm cabinets and can work at the same time.Enbon R3 rental product is the perfect choice for high-end users,Both indoor and outdoor.
┃ Product Parameters
Indoor | Outdoor | |||||
Pixel patch | 1.953 | 2.604 | 2.976 | 3.91 | 3.91 | 4.81 |
LED lamp | SMD1515 | SMD2020 | SMD2020 | SMD2020 | SMD1921 | SMD1921 |
Density | 262144dots/m2 | 147456dots/m2 | 112896dots/m2 | 65536dots/m2 | 65536dots/m2 | 43264dots/m2 |
Brightness | 800-1000nits | 800-1000nits | 800-1000nits | 800-1000nits | ≥ 3500nits | ≥ 3500nits |
IP rating | IP31 | IP31 | IP31 | IP31 | IP65 | IP65 |
Cabinet Materiel | Die-casting Aluminum | |||||
Scan | 32scan | 24scan | 21scan | 16scan | 16scan | 13scan |
Module weight | 0.5kg | 0.5kg | 0.5kg | 0.5kg | 0.5kg | 0.5kg |
Cabinet Weight | 7.5kg | 7.5kg | 7.5kg | 7.5kg | 8kg | 8kg |
Module size | 250*250mm | 250*250mm | 250*250mm | 250*250mm | 250*500mm | 250*500mm |
Cabinet size | 500*500*85mm | 500*500*85mm | 500*500*85mm | 500*500*85mm | 500*500*85mm | 500*500*85mm |
Module pixel | 128*128dots | 96*96dots | 84*84dots | 64*64dots | 64*128dots | 52*104dots |
Cabinet pixel | 256*256dots | 192*192dots | 168*168dots | 128*128dots | 128*128dots | 104*104dots |
Max power | 650w/sqm | 500w/sqm | 500w/sqm | 500w/sqm | 550w/sqm | 550w/sqm |
Average Power | 230w/sqm | 160w/sqm | 160w/sqm | 160w/sqm | 200w/sqm | 200w/sqm |
Viewing Angle | Horizontal 140(+70/-70) deg Vertical 140(+70/-70)deg | |||||
Control way | Synchronous/asynchronous | |||||
Gray scale | 16bit | |||||
Operating system | AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI | |||||
Work humidity | 10% ~ 90% | |||||
Work temperature | ﹣20 ~﹢65℃ |
