The product features excellent durability. Its metal structure is exquisitely processed by oxidation, polishing, and plating, therefore it will not rust or easily break down.
Products Details

Relying on advanced technology, excellent production capabilities, and perfect service, Enbon takes the lead in the industry now and spreads our Enbon all over the world. Together with our products, our services are also supplied to be the highest-level. led display panel board If you are interested in our new product led display panel board and others, welcome you to contact us.The product is not easy to accumulate dust. Its fins are less likely to get heat which may generate electrostatic discharge which attracts air impurities due to electrostatic discharge.

 Product Description

Enbon Transparent LED display screen is widely applicated in different application, like staging shows, business streets. With transmittance could up to 65%, light transmission and wind penetration couldn't affect its lighting and sight. With low led screen price but high quality, the product is hot-selling on the market. Light led display panel, 6 in l flight case could save transportation fees. Its fast lock between up and down cabinets, creating safety of the product. Special module design makes it look more pleasant. High quality shows its popularity in the screen display market.


 Product Parameters

Pixel Pitch

Indoor: 2.6-5.2, 3.9-7.81, 5.21-10.42, 10.4-10.4

Outdoor: 3.9-7.81, 5.21-10.42,10.4-10.4, 15.6-15.6

LED Package


Indoor: SMD1515(P2.6-5.2) SMD(P3.9-7.81,P5.21-10.42, P10.4-10.4)

Outdoor:SMD1921(P3.9-7.81, P5.21-10.42 ) SMD2727(P10.4-10.4, P15.6-15.6)

Pixel composition

Indoor:1R1G1B(P2.6-5.2, P3.9-7.81,P5.21-10.42, P10.4-10.4 )

Outdoor: 1R1G1B(P3.9-7.81,P5.21-10.42, P10.4-10.4,P15.6-15.6)

Permeability

Indoor:58%(P2.6-5.2) 60%(P3.9-7.81) 67%(P5.21-10.42, P10.4-10.4)

Outdoor:55%(P3.9-7.81) 67%(P5.21-10.42) 58%(P10.4-10.4) 71%(P15.6-15.6)

Brightness


Indoor:1000-4500nits(P2.6-5.2, P3.9-7.81,P5.21-10.42, P10.4-10.4 )

Outdoor: 5000nits(P3.9-7.81,P5.21-10.42, P10.4-10.4,P15.6-15.6)

Cabinet pixel

Indoor: 384*96dots(P2.6-5.2) 256*64dots(P3.9-7.81) 192*48dots(P5.21-10.42) 96*48dots(P10.4-10.4)

Outdoor:256*64dots(P3.9-7.81) 192*48dots(P5.21-10.42) 96*48dots(P10.4-10.4) 64*64dots(P15.6-15.6)

Module pixel


Indoor: 192*48dots(P2.6-5.2) 128*16dots(P3.9-7.81) 96*12dots(P5.21-10.42) 48*12dots(P10.4-10.4)

Outdoor: 128*32dots(P3.9-7.81) 96*24dots(P5.21-10.42) 48*24dots(P10.4-10.4) 32*16dots(P15.6-15.6)

Cabinet size


Indoor: 1000*500mm(P2.6-5.2, P3.9-7.81,P5.21-10.42, P10.4-10.4)

Outdoor:1000*500mm(P3.9-7.81,P5.21-10.42, P10.4-10.4,P15.6-15.6)

Cabinet Weight

Indoor: 6kg(P2.6-5.2, P3.9-7.81,P5.21-10.42, P10.4-10.4)

Outdoor:7.5kg(P3.9-7.81,P5.21-10.42, P10.4-10.4,P15.6-15.6)

Relative Humidity


Indoor: 10%-90%

Outdoor: 10%-90%

Work temperature

Indoor:﹣20 ~﹢65℃

Outdoor: ﹣20 ~﹢65℃

Operating system


Indoor: AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI

Outdoor: AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI

Control way


Indoor: Synchronous/Asynchronous

Outdoor: Synchronous/Asynchronous

Grey Scale


Indoor: 15bit

Outdoor: 15bit

Max Power


Indoor:600w/sqm(P2.6-5.2, P10.4-10.4) 620w/sqm(P3.9-7.81,P5.21-10.42)

Outdoor:800w/sqm(P3.9-7.81,P5.21-10.42, P10.4-10.4,P15.6-15.6)

Average Power


Indoor: 200w/sqm(P2.6-5.2, P3.9-7.81,P5.21-10.42, P10.4-10.4)

Outdoor:260w/sqm(P3.9-7.81,P5.21-10.42, P10.4-10.4,P15.6-15.6)

Input Voltage


Indoor:AC100-240V(P2.6-5.2, P3.9-7.81,P5.21-10.42, P10.4-10.4)

Outdoor: AC100-240V(P3.9-7.81,P5.21-10.42, P10.4-10.4,P15.6-15.6)

Refresh Rate


Indoor:1920-3840Hz

Outdoor:1920-3840HZ

IP Rate


Indoor: IP33

Outdoor: IP65

Viewing Angle


Indoor: H140(+70/-70) deg V140(+70/-70)deg

Outdoor: H140(+70/-70) deg V140(+70/-70)deg

Density

Indoor: 73728dots/m2(P2.6-5.2) 32768dots/m2(P3.9-7.81) 18432dots/m2(P5.21-10.42) 9216dots/m2(P10.4-10.4)

Outdoor: 32768dots/m(P3.9-7.81) 18432dots/m2(P5.21-10.42) 9216dots/m2(P10.4-10.4) 4096dots/m2(P15.6-15.6)
