Enbon outdoor waterproof cylindrical display screen, the mask is made of special UV material that is flame-retardant and anti-corrosion, the long-strip display unit design, the maintenance idea of front and rear maintenance, the cylindrical screen project of any diameter, easy maintenance, high protection level, can To achieve the spacing of high-definition P3, it is more suitable for the needs of close-range high-definition projects.
● Front service, easy maintaince
● Small size modules 40mm*320mm
● 360 degree omnidirectional view
● Wide-area perspective
● No dead angle of observation
● Waterproof design
● Customized and creative
● Diverse application
1
| Unit Module | Item | Parameter |
| Model Number | SC-P5(8*64) | |
| Pixel Configuration | 1R1G1B | |
| Package | SMD1921/2727 | |
| Pixel Pitch | 5mm | |
| Brightness of White Balance | 5500-6000cd/m2 | |
| Diameter | ≥800mm | |
| Pixel Density | 40000dots/m2 | |
| Drive Type | Constant Drive | |
| Scan Mode | 1/8 | |
| Weight | 0.9±0.5kg | |
| Module Size | 40mm*320mm | |
| LED Cabinet | Pixel per Cabinet | 192dots(W)*192dots(H) |
| Refresh Frequency | ≥1920Hz | |
| Max Power | 1200w/m2 | |
| Average Power Consumption | 400w/m2 | |
| Grey Scale | 14-16bit | |
| Protection Level | IP65 | |
| Cabinet Material | Iron | |
| Best Viewing Angle | 140°(W) 120°(H) | |
| Best Viewing Distance | 5M-50M | |
| Relative Humidity | 10%-90% | |
| Unit Module | Item | Parameter |
| Model Number | SC-P10(4*32) | |
| Pixel Configuration | 1R1G1B | |
| Package | SMD3535 | |
| Pixel Pitch | 10mm | |
| Brightness of White Balance | 6500-7000cd/m2 | |
| Diameter | ≥800mm | |
| Pixel Density | 10000dots/m2 | |
| Drive Type | Constant Drive | |
| Scan Mode | 1/2 | |
| Weight | 0.9±0.5kg | |
| Module Size | 40mm*320mm | |
| LED Cabinet | Pixel per Cabinet | 96dots(W)*96dots(H) |
| Refresh Frequency | ≥1920Hz | |
| Max Power | 1200w/m2 | |
| Average Power Consumption | 400w/m2 | |
| Grey Scale | 14-16bit | |
| Protection Level | IP65 | |
| Cabinet Material | Iron | |
| Best Viewing Angle | 140°(W) 120°(H) | |
| Best Viewing Distance | 5M-50M | |
| Relative Humidity | 10%-90% | |
