┃ Product Description
Enbon FC-B series is a kind of LED display screen for outdoor fixed front and back service. High brightness for more than 6000nits, bringing full colorful images for audiences. The feature of energy saving brings less fee cost. Installation without wires decreases additional costs. Front maintenance has SMD and DIP modules, creating more possibilities for display installation, it not only has two cabinet installation types-fixed installation and Hanging, but also its cabinet maintenance has front and rear maintenance two ways. High advanced technology makes our product with efficient heart disspation.
┃ Product Parameters
| Pixel Pitch | Outdoor: 4, 5.33, 6.67, 8, 10,16 |
| LED lamp | Outdoor: P4=SMD2727 P5.33=SMD2727 P6.67=SMD2727 P8=SMD2727 P10=SMD2727 P16=SMD2727 |
| Brightness | Outdoor:P4=6000nits P5.33=6000nits P6.67=6000nits P8=6000nits P10=6500nits P16=8500nits |
| Module pixel | Outdoor:P4=80*80dots P5.33=60*60dots P6.67=48*48dots P8=40*40dots P10=32*32dots P16=20*20dot |
| Cabinet pixel | Outdoor:P4=240*240dots P5.33=180*180dots P6.67=144*144dots P8=120*120dots P10=96*96dots P16=60*60dots |
| Module size | Outdoor:P4=320*320mm P5.33=320*320mm P6.67=320*320mm P8=320*320mm P10=320*320mm P16=320*320mm |
| Cabinet size | Outdoor:P4=960x960x120mm P5.33=960x960x120mm P6.67=960x960x120mm P8=960x960x120mm P10=960x960x120mm P16=960x960x120mm |
| Module weight | Outdoor:P4=1.6kg P5.33=1.6kg P6.67=1.6kg P8=1.6kg P10=1.5kg P16=2kg |
| Cabinet Weight | Outdoor:P4=30kg P5.33=30kg P6.67=30kg P8=30kg P10=30kg P16=32kg |
| Storage Temperature | - 40 ℃ ~60 ℃ |
| Operation Temperature | - 20 ℃ ~50℃ |
| Storage Humidity | 10％ ～ 90％ |
| Operation Humidity | 10％ ～ 90％ |
| Gray scale | 14bits |
| Gray Scale per Color | 16384level |
| Refresh Rate | ≥1920Hz |
| Max Power | Outdoor:P4=800w/sqm P5.33=850w/sqm P6.67=800w/sqm P8=850w/sqm P10=700w/sqm P16=400w/sqm |
| Average Power | Outdoor:P4=300w/sqm P5.33=380w/sqm P6.67=300w/sqm P8=380w/sqm P10=240w/sqm P16=130w/sqm |
| IP rating | Outdoor:IP54/IP65 |
| Drive Mode | Outdoor:P4=1/10 P5.33=1/8 P6.67=1/5 P8=1/4 P10=1/2 P16=Static |
| Viewing Angle | Outdoor:P4=140/140(H/V°) P5.33=140/140(H/V°) P6.67=140/140(H/V°) P8=140/140(H/V°) P10=140/140(H/V°) P16=110/60(H/V°) |
| AC input voltage | AC 110/ 220V ± 10% |
| AC input frequency | 60Hz |
| Density | Outdoor:P4=62500dots/m2 P5.33=35344dots/m2 P6.67=22500dots/m2 P8=15625dots/m2 P10=10000dots/m2 P16=3096dots/m2 |
| Cabinet Materie | Die-casting Aluminum |
┃ Product Display
┃ Our Service
Customer Service
1. We can provide customers with professional product advice and purchase options.
2. All emails will be responded within 24 hours during working days.
3. We have online customer service in English, French, Korean and Japanese. You can communicate with ease, or contact us through email anytime.
4. All customers will get one-on-one service.
Customized Service
1. We provide flexible customized services with our abundant experiences in Led screen display D&R.
2. Includes product appearance design, product size, new product development, etc.
3. MOQ is depend on different customized requests.
The Agency Policy
Please contact our sales department for more details.
After Sale Service
1. The warranty of all our products is one year. The specific after-sale plan will be free for replacement or charging a certain maintenance cost according to the specific situations.
2. According to the feedback from markets, we seldom have after-sale problems because strict product inspections are carried out before leaving the factory. And all of our products are certificated by top testing institutions such as TST certification and ATC certification Providing safe and guaranteed products is always one of our greatest strengths.
┃ FAQ
Q: What method do you use to improve luminance and color uniformity?
A: The most important thing is to find out is what your screen manufacturer does to fix the inherent non-uniformity issues found in all LEDs. The method that yields the best results is the PWM correction method, and it often produces a screen that is cheaper than extreme binning methods, because the screen manufacturer does not need to purchase such tight binning lots from the LED manufacturers in order to achieve uniformity. Also, it enables the user to recalibrate the screen as the LEDs become dimmer over the course of several years.
Q : Are correction coefficients used for each pixel or only for each module?
A: For best results, correction coefficients should be provided for each pixel. Correction coefficients for the module can reduce or eliminate the patchwork quilt effect that shows modules with different brightness and color, but it cannot completely remove the boundary differences between different modules and will do nothing to eliminate the dirty window effect caused by pixel-to-pixel uniformity differences
Q: How many correction coefficients are used for each pixel?
A: It is possible to produce correction only for luminance and white point. A screen of this type will use 3x1 correction coefficients (3 coefficients for each pixel). A full color corrected screen will use 3x3 coefficients (9 coefficients for each pixel).
Q: Are the PWM coefficients stored in the modules in addition to storing them in the video controller?
A: The coefficients need to be stored in the video controller in order to perform the video signal processing; however, it is also very convenient to store them in a type of flash memory on the module. This not only provides a backup for the coefficients, but it also enables the module to automatically update the coefficient database in the video controller when it is moved or replaced.
Regarding the attributes and functionality of the leyard video wall, it is a kind of product that will always be in vogue and offer consumers limitless benefits. It can be a long-lasting friend for people because it is constructed from high-quality raw materials and has a lengthy lifespan.
In China, ordinary working time is 40 hours for employees who work full time. In Shenzhen Enbon Optoelectronic Co Ltd, most employees work abiding by this kind of rule. During their duty time, each of them devotes their full concentration to their work so as to provide customers with the highest-quality and an unforgettable experience of partnering with us.
The buyers of leyard video wall come from many businesses and nations around the world. Before they begin working with the manufacturers, some of them may reside thousands of miles away from China and have no knowledge of the Chinese market.
To draw in more users and consumers, industry innovators are continually developing its qualities for a larger range of application scenarios. Additionally, it can be customized for clients and has a reasonable design, all of which help grow the customer base and loyalty.
In essence, a long-standing leyard video wall organization runs on rational and scientific management techniques that were developed by smart and exceptional leaders. The leadership and organizational structures both guarantee that the business will offer competent and high-quality customer service.
Yes, if asked, we will supply relevant technical details regarding Enbon. Basic facts about the products, such as their primary materials, specs, forms, and primary functions, are readily available on our official website.
