Relying on advanced technology, excellent production capabilities, and perfect service, Enbon takes the lead in the industry now and spreads our Enbon all over the world. Together with our products, our services are also supplied to be the highest-level. leyard video wall We promise that we provide every customer with high-quality products including leyard video wall and comprehensive services. If you want to know more details, we are glad to tell you.The product features excellent durability. Its metal structure is exquisitely processed by oxidation, polishing, and plating, therefore it will not rust or easily break down.
┃Product Description
FR series is kind of high brightness waterproof outdoor fixed installation led display screen. Multiple installation methods support embedded installation in different ways. As PWM IC driver was applied on FR Series, it enhances visual refresh rate by reinforcing pulse wave width and dividing conducting time to numbers of shorter conducting time. Besides, GCLK frequency multiplier increases GCLK frequency to realize doubling refresh rate, not only refresh rate, FR series grayscale also benefits from PWM IC driver, cause it at low grayscale, grayscale is smoother compared with common IC driver, bring pleasure feeling for watching.
┃ Product Parameters
| Pixel Pitch | Outdoor: 2.5, 3, 3.33, 4, 5, 6 |
| LED lamp | Outdoor: SMD1415(P2.5, P3) SMD1921(P3.33, P4,P5) SMD2727(P6) |
| Brightness | Outdoor:6800nits(P2.5) 6500nits(P3) 6000nits(P3.33, P6) 5500nits(P4) 5200nits(P5) |
| Module pixel | Outdoor:P2.5=128*64dots P3=104*52dots P3.33=96*48dots P4=80*40dots P5=64*32dots P6=48*24dots |
| Cabinet pixel | Outdoor:P2.5=384*384dots P3=312*312dots P3.33=288*288dots P4=240*240dots P5=192*192dots P6=160*160dots |
| Module size | Outdoor:320*160mm(P2.5, P3, P3.33, P4, P5, P6) |
| Cabinet size | Outdoor:960x960x120mm(P2.5, P3, P3.33, P4, P5, P6) |
| Module weight | Outdoor:0.5kg(P2.5, P3, P3.33, P4, P5, P6) |
| Cabinet Weight | Outdoor: 28kg(P2.5, P3, P3.33, P4, P5, P6) |
| Storage Humidity | 10％ ～ 90％ |
| Operation Humidity | 10％ ～ 90％ |
| Storage Temperature | - 40 ℃ ~60 ℃ |
| Operation Temperature | ﹣20 ～﹢50℃ |
| Gray Scale per Color | 16384level |
| Gray scale | 14bits |
| Refresh Rate | ≥3840Hz |
| Max Power | Outdoor:1000w/sqm(P2.5) 950w/sqm(P3) 980w/sqm(P3.33, P4) 780w/sqm(P5) 580w/sqm(P6) |
| Average Power | Outdoor:350w/sqm(P2.5) 320w/sqm(P3, P3.33, P4) 260w/sqm(P5) 200w/sqm(P6) |
| IP rating | Outdoor:IP54/IP65 |
| Drive Mode | Outdoor:1/16(P2.5) 1/13(P3) 1/12(P3.33) 1/10(P4) 1/8(P5) 1/6(P6) |
| Viewing Angle | 140/140(H/V°) |
| AC input voltag | AC 110/ 220V ± 10% |
| AC input frequency | 60Hz |
| Density | Outdoor:P2.5=160000dots/m2 P3=105625dots/m2 P3.33=90000dots/m2 P4=62500dots/m2 P5=40000dots/m2 P6=27889dots/m2 |
| Cabinet Materiel | Die-casting Aluminum |
| Pixel Pitch | Outdoor: 8, 10, 10 |
| LED lamp | SMD3535 |
| Brightness | Outdoor: 6000nits(P8) 7000-7500nits(P10) 5500nits(P10) |
| Module pixel | Outdoor:40x20dots(P8) 32x16dots(P10, P10) |
| Cabinet pixel | Outdoor:120*120dots(P8) 96*96dots(P10, P10) |
| Module size | Outdoor:320*160mm(P8, P10,P10) |
| Cabinet size | Outdoor:960x960x120mm(P8, P10,P10) |
| Module weight | Outdoor:0.5kg(P8, P10,P10) |
| Cabinet Weight | Outdoor:28kg(P8, P10,P10) |
| Storage Humidity | - 40 ℃ ~60 ℃ |
| Operation Humidity | - 20 ℃ ~50 ℃ |
| Storage Temperature | 10％ ～ 90％ |
| Operation Temperature | 10％ ～ 90％ |
| Gray Scale per Color | 16,384level |
| Gray scale | 14bit |
| Refresh Rate | ≥3840Hz |
| Max Power | Outdoor: 800w/sqm(P8) 750w/sqm(P10, P10) |
| Average Power | Outdoor:230w/sqm(P8) 150w/sqm(P10) |
| IP rating | Outdoor: IP54/IP65 |
| Drive Mode | Outdoor:1/5(P8) 1/2(P10) 1/4(P10) |
| Viewing Angle | 140/140 |
| AC input voltag | AC 110/ 220V ± 10% |
| AC input frequency | 60Hz |
| Density | Outdoor:15625dots/m2(P8) 10000dots/m2(P10, P10) |
| Cabinet Materiel | Die-casting Aluminum |
┃ Product Display
┃ About Enbon
Enbon founded in February 2012, is one of the leading producers of indoor and outdoor different type led screen. Enbon is also a high-tech enterprise integrating R & D, manufacturing and sales. Enbon has 10 software and hardware engineers with 10 years of research and development experience, and 3 high-tech talents with 10 years of display management experience. Providing professional OEM / ODM services. Enbon has more than 150 employees, and provides customized and professional project products and services as its core competitiveness. Enbon products cover two series of direct plug-in (DIP) and SMD surface mount, which fully meets the requirements of different point spacing, visual distance, brightness and environmental requirements for applications. Established a complete product development, production and quality management system, It has 8 fully-automatic imported SMT production lines, 4 fully-automatic printing machines, and 2 fully automatic drying lines for outdoor products, which can fully meet the needs of different orders and specifications. The products have passed CCC, FCC, CE, IAF, ROHS and other international Standard certification, product and enterprise qualification certification, product test report and patent certificates are complete. Enbon Factory, Since the development of Enbon, the marketing network has spread all over the world. At present, it has its own sales centers in South Korea, Japan, India and Qatar, and its products are exported to more than 80 countries and regions in the world. There are sales centers in Yangzhou, Sichuan, Hunan, and Shanghai of China, and the sales network keeps expanding.Enbon Display has won many important honorary titles such as "Top Ten Engineering Brands", "Top Ten Channel Brands", "China Famous (Famous) Brands", "China Green Environmental Protection Brands" and many other industries. Quality is the life of an enterprise. Enbon believes that product quality is the most direct strength of a company. Enbon has undergone strict checks from the raw material inspection of the product to the production process to ensure that the product quality management system and quality control are in the leading position in the industry. In order to achieve the improvement of product quality, we continue to carry out technological innovation, introduce advanced testing equipment and automated production equipment, and gradually optimize every detail in the production process, constantly to "zero defects, zero customer complaints, zero diffusion".
